Modern AM271P 11M一體成型電腦

Modern AM271P 11M

Differences are marked in red	Modern AM271P 11M-604TW	Modern AM271P 11M-605TW	Modern AM271P 11M-607TW	Modern AM271P 11M-606TW	Modern AM271P 11M-608TW
作業系統	N/A	N/A	N/A	N/A	N/A
EAN	4719072916428	4719072916435	4719072921668	4719072921675	4719072921682
型號	9S6-AF8111-604	9S6-AF8111-605	9S6-AF8111-628	9S6-AF8112-627	9S6-AF8112-629
產品名稱	Modern AM271P 11M	Modern AM271P 11M	Modern AM271P 11M	Modern AM271P 11M	Modern AM271P 11M
產品型號規格	Modern AM271P 11M-604TW	Modern AM271P 11M-605TW	Modern AM271P 11M-607TW	Modern AM271P 11M-606TW	Modern AM271P 11M-608TW
顏色	ID1/Black-Black-Black	ID1/Black-Black-Black	ID1/Black-Black-Black	ID1/White-White-White	ID1/White-White-White
螢幕尺寸	27" (69 cm)	27" (69 cm)	27" (69 cm)	27" (69 cm)	27" (69 cm)
顯示區域(公釐)	597.888(H) × 336.312(V)	597.888(H) × 336.312(V)	597.888(H) × 336.312(V)	597.888(H) × 336.312(V)	597.888(H) × 336.312(V)
曲率	Flat	Flat	Flat	Flat	Flat
面板類型	IPS	IPS	IPS	IPS	IPS
解析度	1920x1080 (FHD)	1920x1080 (FHD)	1920x1080 (FHD)	1920x1080 (FHD)	1920x1080 (FHD)
像素間距	0.3114(H)X0.3114(V)	0.3114(H)X0.3114(V)	0.3114(H)X0.3114(V)	0.3114(H)X0.3114(V)	0.3114(H)X0.3114(V)
亮度 (nits)	300	300	300	300	300
對比度	1000:1	1000:1	1000:1	1000:1	1000:1
Signal Frequency	56~84.5 KHz(H) / 50~75 Hz(V)	56~84.5 KHz(H) / 50~75 Hz(V)	56~84.5 KHz(H) / 50~75 Hz(V)	56~84.5 KHz(H) / 50~75 Hz(V)	56~84.5 KHz(H) / 50~75 Hz(V)
反應時間 (GTG)	14ms	14ms	14ms	14ms	14ms
可視角度	178°(H)/178°(V)	178°(H)/178°(V)	178°(H)/178°(V)	178°(H)/178°(V)	178°(H)/178°(V)
表面處理	Anti-Glare	Anti-Glare	Anti-Glare	Anti-Glare	Anti-Glare
觸控螢幕	Non-touch	Non-touch	Non-touch	Non-touch	Non-touch
顯示色彩	16.7M	16.7M	16.7M	16.7M	16.7M
Lock type	Kensington	Kensington	Kensington	Kensington	Kensington
處理器型號	Intel Core i5-1135G7	Intel Core i7-1165G7	Intel Core i5-1135G7	Intel Core i5-1135G7	Intel Core i5-1135G7
處理器時脈	2.4GHz	2.8GHz	2.4GHz	2.4GHz	2.4GHz
處理器核心數	4	4	4	4	4
散熱設計功率	28W	28W	28W	28W	28W
快取記憶體	8 MB Intel® Smart Cache	12 MB Intel® Smart Cache	8 MB Intel® Smart Cache	8 MB Intel® Smart Cache	8 MB Intel® Smart Cache
執行緒	8	8	8	8	8
記憶體	Memory Size 8GB(8GB*1) Memory Type DDR4 SDRAM Memory Speed 1600(3200)MHz Module Type SO-DIMM Memory Slot(Total) 2 Memory Slot(Free) 1 Max Capacity Max 64GB	Memory Size 8GB(8GB*1) Memory Type DDR4 SDRAM Memory Speed 1600(3200)MHz Module Type SO-DIMM Memory Slot(Total) 2 Memory Slot(Free) 1 Max Capacity Max 64GB	Memory Size 8GB(8GB*1) Memory Type DDR4 SDRAM Memory Speed 1600(3200)MHz Module Type SO-DIMM Memory Slot(Total) 2 Memory Slot(Free) 1 Max Capacity Max 64GB	Memory Size 8GB(8GB*1) Memory Type DDR4 SDRAM Memory Speed 1600(3200)MHz Module Type SO-DIMM Memory Slot(Total) 2 Memory Slot(Free) 1 Max Capacity Max 64GB	Memory Size 8GB(8GB*1) Memory Type DDR4 SDRAM Memory Speed 1600(3200)MHz Module Type SO-DIMM Memory Slot(Total) 2 Memory Slot(Free) 1 Max Capacity Max 64GB
儲存裝置	SSD Size 512GB(512GB*1) SSD Form Factor M.2-2280 M-KEY M.2 slots(Total) 1 M.2 slots(Free) 0 3.5" Drive Bays(Free) 0 2.5" Drive Bays(Total) 1 2.5" Drive Bays (Free) 1	SSD Size 512GB(512GB*1) SSD Form Factor M.2-2280 M-KEY M.2 slots(Total) 1 M.2 slots(Free) 0 3.5" Drive Bays(Free) 0 2.5" Drive Bays(Total) 1 2.5" Drive Bays (Free) 1	SSD Size 512GB(512GB*1) SSD Form Factor M.2-2280 M-KEY M.2 slots(Total) 1 M.2 slots(Free) 0 3.5" Drive Bays(Free) 0 2.5" Drive Bays(Total) 1 2.5" Drive Bays (Free) 1	SSD Size 512GB(512GB*1) SSD Form Factor M.2-2280 M-KEY M.2 slots(Total) 1 M.2 slots(Free) 0 3.5" Drive Bays(Free) 0 2.5" Drive Bays(Total) 1 2.5" Drive Bays (Free) 1	SSD Size 512GB(512GB*1) SSD Form Factor M.2-2280 M-KEY M.2 slots(Total) 1 M.2 slots(Free) 0 3.5" Drive Bays(Free) 0 2.5" Drive Bays(Total) 1 2.5" Drive Bays (Free) 1
固態硬碟介面	PCIe GEN3x4	PCIe GEN3x4	PCIe GEN3x4	PCIe GEN3x4	PCIe GEN3x4
有線網路型號	Realtek RTL8111H	Realtek RTL8111H	Realtek RTL8111H	Realtek RTL8111H	Realtek RTL8111H
無線網路	INTEL/AX201.NGWG.NVW	INTEL/AX201.NGWG.NVW	INTEL/AX201.NGWG.NVW	INTEL/AX201.NGWG.NVW	INTEL/AX201.NGWG.NVW
無線網路版本	802.11ax 2x2+BT	802.11ax 2x2+BT	802.11ax 2x2+BT	802.11ax 2x2+BT	802.11ax 2x2+BT
藍牙版本	5.2	5.2	5.2	5.2	5.2
音效	Realtek ALC233, 2.1 Channel HD Audio	Realtek ALC233, 2.1 Channel HD Audio	Realtek ALC233, 2.1 Channel HD Audio	Realtek ALC233, 2.1 Channel HD Audio	Realtek ALC233, 2.1 Channel HD Audio
連接埠 (正面)	2 x USB 3.2 Gen 2 Type A 2 x USB 3.2 Gen 2 Type C	2 x USB 3.2 Gen 2 Type A 2 x USB 3.2 Gen 2 Type C	2 x USB 3.2 Gen 2 Type A 2 x USB 3.2 Gen 2 Type C	2 x USB 3.2 Gen 2 Type A 2 x USB 3.2 Gen 2 Type C	2 x USB 3.2 Gen 2 Type A 2 x USB 3.2 Gen 2 Type C
音源複合連接埠 (麥克風輸入、耳機輸出)	1	1	1	1	1
USB 2.0 Type A (背面)	2	2	2	2	2
RJ45	1	1	1	1	1
HDMI™ 輸出	1x (v2.0)	1x (v2.0)	1x (v2.0)	1x (v2.0)	1x (v2.0)
HDMI™ in	1	1	1	1	1
AC電源變壓器規格	120W	120W	120W	120W	120W
鍵盤規格	WIRELESS	WIRELESS	WIRELESS	WIRELESS	WIRELESS
滑鼠規格	WIRELESS	WIRELESS	WIRELESS	WIRELESS	WIRELESS
電源線	1	1	1	1	1
AC電源變壓器	1	1	1	1	1
Warranty Card	1	1	1	1	1
快速指南	2	2	2	2	2
鍵盤	RF1430	RF1430	RF1430	RF1430W	RF1430W
滑鼠	MA04	MA04	MA04	MA04W	MA04W
視訊網路攝影機	external webcam	external webcam	external webcam	external webcam	external webcam
操作／儲存溫度	0° C ~ 35° C ; -20° C ~ 60° C	0° C ~ 35° C ; -20° C ~ 60° C	0° C ~ 35° C ; -20° C ~ 60° C	0° C ~ 35° C ; -20° C ~ 60° C	0° C ~ 35° C ; -20° C ~ 60° C
操作／儲存濕度	0% ~ 85%;0% ~ 90%	0% ~ 85%;0% ~ 90%	0% ~ 85%;0% ~ 90%	0% ~ 85%;0% ~ 90%	0% ~ 85%;0% ~ 90%
認證	FCC(Class B) CB/CE UL(CUL) BSMI VCCI RCM(C-Tick)	FCC(Class B) CB/CE UL(CUL) BSMI VCCI RCM(C-Tick)	FCC(Class B) CB/CE UL(CUL) BSMI VCCI RCM(C-Tick)	FCC(Class B) CB/CE UL(CUL) BSMI VCCI RCM(C-Tick)	FCC(Class B) CB/CE UL(CUL) BSMI VCCI RCM(C-Tick)
腳架調整角度(俯仰角)	YES	YES	-4°~20°	-4°~20°	-4°~20°
ADJUSTMENT (HEIGHT)	N/A	N/A	0~130mm	0~130mm	0~130mm
產品尺寸 (寬X深X高)(含支架／公釐)	611.75 x 169.96 x 436.06	611.75 x 169.96 x 436.06	611.75 x 169.96 x 436.06	611.75 x 169.96 x 436.06	611.75 x 169.96 x 436.06
產品尺寸 (寬X深X高)(含支架／英吋)	24.08 x 6.69 x 17.17	24.08 x 6.69 x 17.17	24.08 x 6.69 x 17.17	24.08 x 6.69 x 17.17	24.08 x 6.69 x 17.17
重量 (淨重／公斤)	7.42	7.42	7.42	7.42	7.42
重量 (毛重／公斤)	10	10	10	10	10
保固	36M	36M	36M	36M	36M
