[Taipei, Taiwan] 全球電競硬體領導品牌，MSI推出由 NVIDIA® GeForce RTX™ 40 系列圖形處理器提供支持的全新顯示卡系列－GAMING SLIM。承襲過往MSI GAMING 系列最具標誌性的 GAMING元素，GAMING SLIM 在確保高效能的同時，提供更薄、更輕，更適合靈活的系統組裝使用。GAMING SLIM系列將用於GeForce RTX 4090、GeForce RTX 4080、GeForce RTX 4070 Ti、GeForce RTX 4070 和 GeForce RTX 4060 Ti 圖形處理器。
纖薄有型 全力出擊
GAMING SLIM提供黑色和白色兩種版本，透過大膽的線條、俐落的邊緣和時尚外觀的RGB 色調體現出玩家勇於冒險的 GAMING本色。隱藏在纖薄外型中，優異的散熱能力絲毫不受影響。由 MSI 最新一代散熱解決方案 TRI FROZR 3 驅動的散熱系統，採用 TORX FAN 5.0以及透過外框連接的成對三個風扇葉片，形成了一個邊框將氣流引導到下方更新的散熱模組中。同時亦具有鍍鎳銅底座和位於散熱器中心的多達 8 個芯管，益於有效散熱。此外，流通式設計的金屬背板同時增強了散熱性和卡的強度。Mystic Light 能使用 Mystic Light Sync 和 Ambient Link 與其他PC 組件同步燈效。
更吸引熱血玩家的選擇
GAMING SLIM 比GAMING 系列更輕、更薄，更適合在較小機箱空間內構建遊戲配備的玩家量身訂製。其可確保電腦機箱內的最佳氣流和循環。此外，配備一流的散熱設計以及光線追踪和 NVIDIA DLSS 等先進功能，可以更輕鬆地享受無與倫比的速度，開創效能、沉浸式遊戲、AI功能和快如閃電的內容創作的嶄新時代。GAMING SLIM 系列非常適合創作專業人士、電競選手、直播主、創作者等。
MSI AFTERBURNER
MSI Afterburner 是全球知名度最高、使用最廣泛的顯示卡超頻軟體。其提供對顯示卡的完全控制，並讓使用者能夠即時監控關鍵系統指標。Afterburner 為流暢的遊戲體驗提供了免費的效能提升，高幀數提供更順暢的遊戲體驗。
MSI CENTER
獨家MSI Center軟體透過簡單好用的應用程式，提升使用者體驗。其具有Frozr AI 散熱功能，將連接到相容的 MSI 主板系統風扇統一起來，以對 GPU 散熱變化做出應對。
Product Specifications
MODEL NAME
GeForce RTX™ 4070 Ti GAMING X SLIM 12G
GeForce RTX™ 4070 Ti GAMING SLIM 12G
GeForce RTX™ 4070 Ti GAMING X SLIM WHITE 12G
GeForce RTX™ 4070 Ti GAMING SLIM WHITE 12G
GPU
NVIDIA® GeForce RTX™ 4070 Ti
NVIDIA® GeForce RTX™ 4070 Ti
NVIDIA® GeForce RTX™ 4070 Ti
NVIDIA® GeForce RTX™ 4070 Ti
INTERFACE
PCI Express® Gen 4
PCI Express® Gen 4
PCI Express® Gen 4
PCI Express® Gen 4
CUDA® CORES
7680 Units
7680 Units
7680 Units
7680 Units
CORE CLOCKS
Extreme Performance: 2745 MHz (MSI Center)
Boost: 2730 MHz
Extreme Performance: 2625 MHz (MSI Center)
Boost: 2610 MHz
EExtreme Performance: 2745 MHz (MSI Center)
Boost: 2730 MHz
Extreme Performance: 2625 MHz (MSI Center)
Boost: 2610 MHz
MEMORY SPEED
21 Gbps
21 Gbps
21 Gbps
21 Gbps
MEMORY
12GB GDDR6X
12GB GDDR6X
12GB GDDR6X
12GB GDDR6X
MEMORY BUS
192-bit
192-bit
192-bit
192-bit
OUTPUT
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a)
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a)
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a)
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a)
HDCP SUPPORT
Y
Y
Y
Y
POWER CONSUMPTION
285 W
285 W
285 W
285 W
POWER CONNECTORS
16-pin x1
16-pin x1
16-pin x1
16-pin x1
RECOMMENDED PSU
700 W
700 W
700 W
700 W
CARD DIMENSION (MM)
307 x 125 x 51 mm
307 x 125 x 51 mm
307 x 125 x 51 mm
307 x 125 x 51 mm
WEIGHT (CARD / PACKAGE)
1086 g / 1843 g
1086 g / 1843 g
1086 g / 1843 g
1086 g / 1843 g
DIRECTX VERSION SUPPORT
12 Ultimate
12 Ultimate
12 Ultimate
12 Ultimate
OPENGL VERSION SUPPORT
4.6
4.6
4.6
4.6
MAXIMUM DISPLAYS
4
4
4
4
G-SYNC® TECHNOLOGY
Y
Y
Y
Y
DIGITAL MAXIMUM RESOLUTION
7680 x 4320
7680 x 4320
7680 x 4320
7680 x 4320
MODEL NAME
GeForce RTX™ 4070 GAMING X SLIM 12G
GeForce RTX™ 4070 GAMING SLIM 12G
GeForce RTX™ 4070 GAMING X SLIM WHITE 12G
GeForce RTX™ 4070 GAMING SLIM WHITE 12G
GPU
NVIDIA® GeForce RTX™ 4070
NVIDIA® GeForce RTX™ 4070
NVIDIA® GeForce RTX™ 4070
NVIDIA® GeForce RTX™ 4070
INTERFACE
PCI Express® Gen 4
PCI Express® Gen 4
PCI Express® Gen 4
PCI Express® Gen 4
CUDA® CORES
5880 Units
5880 Units
5880 Units
5880 Units
CORE CLOCKS
Extreme Performance: 2625 MHz (MSI Center)
Boost: 2610 MHz
Extreme Performance: 2490 MHz (MSI Center)
Boost: 2475 MHz
Extreme Performance: 2625 MHz (MSI Center)
Boost: 2610 MHz
Extreme Performance: 2490 MHz (MSI Center)
Boost: 2475 MHz
MEMORY SPEED
21 Gbps
21 Gbps
21 Gbps
21 Gbps
MEMORY
12GB GDDR6X
12GB GDDR6X
12GB GDDR6X
12GB GDDR6X
MEMORY BUS
192-bit
192-bit
192-bit
192-bit
OUTPUT
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a)
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a)
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a)
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a)
HDCP SUPPORT
Y
Y
Y
Y
POWER CONSUMPTION
215 W
215 W
215 W
215 W
POWER CONNECTORS
16-pin x1
16-pin x1
16-pin x1
16-pin x1
RECOMMENDED PSU
650 W
650 W
650 W
650 W
CARD DIMENSION (MM)
307 x 125 x 46 mm
307 x 125 x 46 mm
307 x 125 x 46 mm
307 x 125 x 46 mm
WEIGHT (CARD / PACKAGE)
988 g / 1750 g
988 g / 1750 g
988 g / 1750 g
988 g / 1750 g
DIRECTX VERSION SUPPORT
12 Ultimate
12 Ultimate
12 Ultimate
12 Ultimate
OPENGL VERSION SUPPORT
4.6
4.6
4.6
4.6
MAXIMUM DISPLAYS
4
4
4
4
G-SYNC® TECHNOLOGY
Y
Y
Y
Y
DIGITAL MAXIMUM RESOLUTION
7680 x 4320
7680 x 4320
7680 x 4320
7680 x 4320
MODEL NAME
GeForce RTX™ 4060 Ti GAMING X SLIM 16G
GeForce RTX™ 4060 Ti GAMING SLIM 16G
GeForce RTX™ 4060 Ti GAMING X SLIM WHITE 16G
GeForce RTX™ 4060 Ti GAMING SLIM WHITE 16G
GPU
NVIDIA® GeForce RTX™ 4060 Ti
NVIDIA® GeForce RTX™ 4060 Ti
NVIDIA® GeForce RTX™ 4060 Ti
NVIDIA® GeForce RTX™ 4060 Ti
INTERFACE
PCI Express® Gen 4 x 8
PCI Express® Gen 4 x 8
PCI Express® Gen 4 x 8
PCI Express® Gen 4 x 8
CUDA® CORES
4325 Units
4325 Units
4325 Units
4325 Units
CORE CLOCKS
Extreme Performance: 2685 MHz (MSI Center)
Boost: 2670 MHz
Extreme Performance: 2550 MHz (MSI Center)
Boost: 2535 MHz
Extreme Performance: 2685 MHz (MSI Center)
Boost: 2670 MHz
Extreme Performance: 2550 MHz (MSI Center)
Boost: 2535 MHz
MEMORY SPEED
18 Gbps
18 Gbps
18 Gbps
18 Gbps
MEMORY
16GB GDDR6
16GB GDDR6
16GB GDDR6
16GB GDDR6
MEMORY BUS
128-bit
128-bit
128-bit
128-bit
OUTPUT
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR and 8K@60Hz HDR and Variable Refresh Rate (VRR) as specified in HDMI 2.1a)
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR and 8K@60Hz HDR and Variable Refresh Rate (VRR) as specified in HDMI 2.1a)
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR and 8K@60Hz HDR and Variable Refresh Rate (VRR) as specified in HDMI 2.1a)
DisplayPort x 3 (v1.4a)
HDMI™ x 1 (Supports 4K@120Hz HDR and 8K@60Hz HDR and Variable Refresh Rate (VRR) as specified in HDMI 2.1a)
HDCP SUPPORT
Y
Y
Y
Y
POWER CONSUMPTION
165 W
165 W
165 W
165 W
POWER CONNECTORS
8-pin x1
8-pin x1
8-pin x1
8-pin x1
RECOMMENDED PSU
550 W
550 W
550 W
550 W
CARD DIMENSION (MM)
307 x 125 x 46 mm
307 x 125 x 46 mm
307 x 125 x 46 mm
307 x 125 x 46 mm
WEIGHT (CARD / PACKAGE)
919 g / 1636 g
919 g / 1636 g
919 g / 1636 g
919 g / 1636 g
DIRECTX VERSION SUPPORT
12 Ultimate
12 Ultimate
12 Ultimate
12 Ultimate
OPENGL VERSION SUPPORT
4.6
4.6
4.6
4.6
MAXIMUM DISPLAYS
4
4
4
4
G-SYNC® TECHNOLOGY
Y
Y
Y
Y
DIGITAL MAXIMUM RESOLUTION
7680 x 4320
7680 x 4320
7680 x 4320
7680 x 4320
